UL Certified M16 7.6mm Circular Plastic Connectors

Name: UL Certified M16 76mm Circular Plastic Connectors
Brand: HFYD
Price: 1 USD

Brand Name : HFYD

Model Number : SA16

Certification : UL, CE, RoHS, IP68

Place of Origin : Guangdong, China

MOQ : 200/500

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10000 pcs per day

Delivery Time : 5~12 days as per order quantities

Packaging Details : 80pcs/bag, 320pcs/carton

Material : Nylon PA66

Color : Black

Protection Level : IP68

Termination : Solder termination

Max Cable OD : 7.6mm

Numbers of Pins : 2+3 pins

Pin Material : Brass

Finish : Gold

Contact Now

UL Certified M16 Plastic IP68 Waterproof Cable Connector Nylon 2+3 Pin Auto Lock Connector

Introduction

1) Parts: Male, Female terminals.

2) M16 connector with automatic lock system.

3) Protection level: IP68.

4) Pins: 2+3 pins.

Specification

Connector Type	UL Certified M16 Plastic IP68 Waterproof Cable Connector
Number of Pins	2+3 pins
Applications	For LED outdoor lighting, outdoor wall washer etc
Termination	Solder termination
Locking System	Automatic (push-pull) locking
Waterproof Level	IP68
Contact Resistance	≤5mΩ
Max Wire OD	7.6mm
Seal O-ring	Silicon
Temperature	-40℃~105℃
Shell Meterial	Nylon (PA66)
Rated Voltage	300V
Rated Current	10A+3A
Contact Material	Brass
Contact Finish	Gold

Our advantages:

•We can do the designs according to the customers' requirement or drawings.

•We can open you connectors with high quality & reasonable price.

•Promptly delivery, 2~3 weeks after orders.

•Low MOQ: small orders are welcome.

•Rich experience: over 12 years.

•Professional design team.

•Free samples available.

100% Guarantee Qualtiy

•Quality Guarantee: 3 Years

•Manufactured Under Strict Control

•100% Tested (Not Just Batch Tested)

•OEM supplier for Anphenol, Philips (Signify), OSRAM for over 7 Years

Packing And Delivery

Packaging

1) Normally, our price is based on our box packing for splice connectors.
2) 200pcs to a PE bag packing, 5 bags packing to a carton.
3) Customized packing is welcome , MOQ of printing customized box is 3000 pcs each model.

Delivery

1) 3-5 working days for samples;
2) 5-10 working day for goods, depending on specific orders.
